Out of stock
Franz Binder

M12-A integrated socket, Contacts: 8, not shielded, dip-solder, IP68, UL, for PCB assembly

Product Code : 99 3482 202 08
Stok Durumu : 0
Birim : Adet
Franz Binder
1,002.82 TL + VAT
0 Yorum | Add Comment
Buy wholesale for more discount!
Quantity
Discount
1 - 19
%0
20 - 99
%27
100 - 9999
%44
Alert when in stock
Hafta İçi Saat 15:00'a Kadar Verdiğiniz Siparişler Aynı Gün Kargoda!
Campaign
  • Features
  • Document
  • Payment Options
  • Comments (0)
  • Recommend

  • 99 3482 202 08

    M12, series 713, Automation technology - sensors and actuators

    Features
    Connector Lock
    :
    Screw
    Contact Type
    :
    Female
    Degree of Protection
    :
    IP68
    Number of Poles
    :
    8
    Coding
    :
    A Coding
    Contacts Supplied
    :
    Yes
    Shell Size
    :
    M12
    Rated Voltage
    :
    30 V
    Rated Current
    :
    1.50 A
    Termination Type
    :
    Solder Pin
    Lower Limit Temperature (°C)
    :
    -40
    Upper Limit Temperature (°C)
    :
    85
    Contact Material
    :
    CuSn (bronze)
    Contact Surface
    :
    Au (Gold)
    Housing Material
    :
    CuZn
    Mechanical Life
    :
    > 100
    Rated Impulse Voltage
    :
    800 V
    Overvoltage Category
    :
    II
    Insulation Resistance
    :
    > 10⁸ Ω
    Insulation Group
    :
    III
    Volume Resistance
    :
    ≤ 3 mΩ
    EMC Suitability
    :
    No
    Standards
    :
    UL
